Self-Service Vacuum

Call for Price

High-performance self-service vacuums are part of the overall concept of a self-service wash system

Models

Mono
Duo

Category: Ehrle

Description

Description

Model	Mono	Duo
Order N°	19702	19801
Vacuum power	1700 l/min	2 x 1700 l/min
Vakuum	230 mbar	2 x 230 mbar
Dirt container volume	70 l	2 x 70 l
Vacuum hose length	500 cm	2 x 500 cm
Noise level	66 / 57,5 dB(A) (with soundproofing)	66 / 57,5 dB(A) (with soundproofing)
Power type	3 Ph / 400 V / 50 Hz	3 Ph / 400 V / 50 Hz
Power intake	2,3 kW	4,6 kW
Weight	400 kg	450 kg
Dimensions	120 x 80 x 300 cm	120 x 80 x 300 cm

Strong vacuum power – extremely quiet

Three-phase current turbine with side channel compressor
Side channel compressor speed: 2800 rpm
Noise level: 66 dB(A) at a distance of 5 mn in the standard design
Noise level: 57.5 dB(A) at a distance of 5 m with soundproofing (extra accessory)

Perfect hose guidance system

Overhead hose guidance system
Simple vacuum hose handling from above
No ground contact and therefore low wear and soiling of the vacuum hose and vacuum nozzle
Large sized vacuum hose holder on the side

Stainless steel as an option

Entire unit housing made of polished stainless steel
Stainless steel vacuum pipe with 180° rotation
Stainless steel dirt container
